Semi-Automatic Coagulation Analyzer NSAA-102

Semi-Automatic Coagulation Analyzer NSAA-102 offers dual testing channels for analyzing two different items simultaneously. It requires 20 to 40 µL of both sample and reagent per test, offering flexibility in volume. Our unit has a sample pre-warming system with 16 positions and a reagent pre-warming system with 4 positions for optimal temperature control. It includes an electronically-linked pipette for precise sample handling. This analyzer comes with an inner thermal-sensitive printer for convenient result printing.

---

$2,263.00

Buy Now Catalog

Specifications

Testing channels	2
Test wavelength	470nm
Testing parameters	PT, APTT, TT, FIB, and Clotting factors
Sample pre-warming position	16 positions
Reagent pre-warming position	4 positions
Sample consumption	20 to 40µL
Reagent consumption	20 to 40µL
Temperature range	15 to 30°C
Temperature control precision	37 ±0.3°C
Humidity	≤90%
Test precision	CV<2%
Coincidence indicator	≤3%
Memory	10,000 test results
Notation of result	S, %, PTR, INR, g/L
Display screen	5 inches LCD
Printer	Thermal-sensitive printer
Power supply	220VAC ±15%, 50/60Hz
Dimension	395×320×135mm
Weight	6kg

Features

• Memory for 10,000 results
• RS232 interface for PC connection
• Real-time data display
• Supports routine coagulation tests
• Automatic test result notation
• Advanced optical light matching system
• Optional PT-derived method for fibrinogen
• Easy calibration and maintenance

Applications

• Semi-Automatic Coagulation Analyzer NSAA-102 is used for precise and efficient coagulation testing. It is widely used in clinical laboratories, hospitals, and medical research facilities for diagnosing and monitoring blood clotting disorders.
