Stage Top Incubator NSTI-100 uses inverted or upright microscopes, and comes with a volume of 6L. It is designed for long-term cell culture and time-lapse imaging. It precisely controls temperature up to 30°C to 40°C and O₂ up to 0.1% to 25%. Our unit is deal for live-cell imaging in hypoxic environments. This cell chamber is used to hold multi-well plates or slides. Our system allows long-term live-cell time-lapse experiments under controlled conditions
$8,525.00
Specifications
| Volume | 6L |
| Type | Stage Top |
| Control mode | External, Programmable |
| Temperature Range | 30°C to 40°C |
| Oxygen Range | 0.1% to 25% |
| Carbon dioxide Range | 0% to 20% |
| Temperature Accuracy | ±0.1°C |
| Oxygen Accuracy | 0.1% |
| Carbon dioxide Accuracy | 0.1%. |
| Microscope compatibility | Upright and inverted microscopes |
| Dimension | 254mm×120mm (ID×H) |
Features
Applications
Ask Expert
FAQ for Stage Top Incubator NSTI-100
1: What is a Stage Top Incubator NSTI-100 used for?
Stage Top Incubator NSTI-100 is used for live-cell imaging and high-resolution imaging of sensitive biological samples and long-term cell culture on an inverted or upright microscope.
2: What temperature range does Stage Top Incubator NSTI-100 support?
Stage Top Incubator NSTI-100 supports 30°C to 40°C, with ±0.1°C accuracy. The temperature ranges can be monitored and customized as it is programmable.
3: What sample formats can Stage Top Incubator NSTI-100 hold?
Stage Top Incubator NSTI-100 accommodates multi-well plates, culture dishes, test tubes, flasks, and small culture vessels and slides. It includes adjustable stainless-steel shelves, allowing flexibility to accommodate various sample.
4: Is Stage Top Incubator NSTI-100 suitable for hypoxic studies?
Yes, Stage Top Incubator NSTI-100 allows precise oxygen control for hypoxia experiments. These incubators are equipped with oxygen sensors and nitrogen gas injection systems
5: Is Stage Top Incubator NSTI-100 programmable?
Yes, Stage Top Incubator NSTI-100 is programmable as it has external control unit that allows customizable settings including temperature, humidity settings.
6: What are stage top incubators for microscope?
Stage top incubators maintain live cell conditions like temperature, CO2 and humidity on a microscope stage. They allow long-term imaging of sensitive biological samples in high resolution.
7: Can the CO2 levels be controlled with stage top incubators?
Yes, stage top incubators come equipped with CO2 regulation systems, allowing precise control of gas concentration. This is important to stabilize the pH of culture media and mimic in vivo conditions necessary for cell health.
8: Are stage top incubators compatible with all types of microscopes?
While most stage top incubators are designed for inverted microscopes, many models or adapters fit for different microscope stages like upright microscopes also.
9: Can long-term time-lapse imaging be performed using a stage top incubator?
Yes, stage top incubators are ideal for time-lapse experiments. They maintain a stable environment, allowing researchers to monitor dynamic processes like cell division, migration, or differentiation over hours or even days without sample degradation.
10: What types of biological samples can be used with stage top incubators?
Stage top incubators can support a wide range of live samples, including adherent cells, suspension cultures, organoids, and small tissue sections. They are especially useful for experiments requiring real-time observation of biological activity.
Stage Top Incubators provide a controlled environment for live cell imaging directly on the microscope stage. These units are designed for precision, maintain stable temperature, humidity, and CO? levels to support cell viability during long-term observation. Our units are ideal for research labs, compatible with various microscope models. Their compact design ensures easy integration without obstructing optics. Our systems are perfect for time-lapse imaging and sensitive biological experiments
