Microwave Digestion System NMDS-301 maintains a temperature accuracy of ±0.5°C and pressure of up to 1500 psi. It is equipped with a large touchscreen for intuitive and easy operation. This unit features a turntable design for uniform microwave distribution. It includes automatic protection functions to ensure safety during use. Our system has a self-locking explosion-proof buffer furnace door for reliable protection.
$6,000.00
Specifications
| Sample capacity | ≥6 samples/batch |
| Vessel capacity | 55 ml |
| Temperature range | 0 to 300°C |
| Maximum Temperature | 300°C |
| Temperature accuracy | ±0.5°C |
| Pressure | 1500 psi |
| Inner tank material | Polytetrafluoroethylene (PTFE) |
| Working mode | Continuous 360° unidirectional rotation |
| Power consumption | 2600 W |
| Power supply | 220 to 240 V AC, 50/60 Hz |
| Dimensions | 507 × 619.5 × 666 mm |
| Weight | 50 kg |
Features
Applications
Ask Expert
FAQ for Microwave Digestion System NMDS-301
1: What should I do if the Microwave Digestion System stops heating unexpectedly?
This could be due to the internal pressure exceeding safety limits. Check the rupture disk, inspect the digestion tank, and review system settings. Always refer to the user manual for safe troubleshooting procedures.
2: What is the role of non-pulse automatic frequency conversion in the Microwave Digestion System?
This feature maintains stable microwave output, enhances system durability, and ensures consistent sample digestion throughout each cycle.
3: Can I monitor temperature and pressure in real-time on the Microwave Digestion System?
Yes, the Microwave Digestion System features a dual control system with real-time infrared temperature detection and pressure monitoring, displayed clearly on an 8-inch touchscreen interface.
4: How does the Microwave Digestion System NMDS-301 ensure uniform heating across all samples?
The Microwave Digestion System uses a 360° rotating turntable and high microwave field uniformity to evenly distribute microwave energy, ensuring each sample is digested under identical conditions.
5: What safety features are built into the Microwave Digestion System NMDS-301?
It includes a self-locking explosion-proof door, pressure cutoff, and a dual-layer rupture disk that safely releases excess pressure, ensuring user and equipment safety.
Labnics Microwave Digestion Systems utilize advanced microwave heating technology for faster sample digestion. These units are equipped with durable vessels resistant to harsh conditions, ensuring long-lasting performance. They continuously display pressure and temperature for each vessel, providing accurate control throughout the process. Our Digestion Systems allow users to adjust key parameters for flexibility in the operation.
