Intelligent Flow Peristaltic Pump NIFPP-600

Intelligent Flow Peristaltic Pump NIFPP-600 offers dispensing times from 0.1 seconds up to 9999 hours and pause times ranging from 0.5 seconds to 9999 seconds. It provides strong resistance to electromagnetic interference for stable performance. Our unit is equipped with a high-precision servo motor for accurate operation. It features a touch screen for easy management and quick setup. This flow peristaltic pump ensures safety with dual circuit isolation for internal and external interfaces.

---

$9,163.00

Buy Now Catalog

Specifications

Flow Range	0.69 to 12000 mL/min
Speed Range	0.1 to 600 RPM
Speed Resolution	0.01 RPM
Dispensing Volume	0.1mL to 9999 L
Dispensing Time	0.1s to 9999 h
Pause Time	0.5s to 9999s
Repeat Number	1 to 9999 times
Motor type	stepper motor
Display	4.3-inch industrial grade
Temperature Range	0 to 40°C
Relative Humidity	<100%
Working Mode	Flow rate mode, dispensing mode
Flow Rate Mode	Continuous transferring according to the set flow rate or motor speed.
Dispensing Mode	Fixed time and volume dispensing: Set the dispensing volume, dispensing time, repeat number and pause time Fixed volume dispensing: Set the dispensing volume, flow rate, repeat number and pause time Speed/time dispensing: Set the motor speed (RPM), dispensing time, repeat number and pause time.
Control Method	Touch screen, Mechanical buttons External signal, Communication
Back Suction Angle	0 to 360°
Communication Interface	RS485/RS232 support MODBUS protocol (RTU mode)
EMC Standard	IEC 60529:2013, Q/BSC01-2019
IP Rate	IP66/IP67/IP68
External Control	0 to 5 V, 0 to 10 V, 4 to 20 mA (option)
External Control Signal Input	5V to 24V active control, Passive switch control (start/stop)
Signal Output	Open collector output operation status
Power Consumption	300 W
Power Supply	AC 110 to 220V±10%, 50Hz/60Hz
Dimension	428 × 285 × 335 mm
Weight	21.2 Kg

Features

• Waterproof performance
• Automatic calibration
• Fully sealed shell structure
• Low maintenance
• Stainless steel bearing

Applications

• Intelligent Flow Peristaltic Pump NIFPP-600 is ideal for pharmaceutical, chemical, environmental monitoring, and water treatment industries, ensuring precise and reliable fluid handling.

Standard Accessories

Silicone tubing (2 meters)

Operation manual × 1 pc

Power cable × 1 pc

Tubing clamps × 1 set
