Fluorescence Microscope NFM-300

Fluorescence Microscope NFM-300 features achromatic objectives ranging from 4X to 100X for detailed specimen observation. This microscope includes a binocular head inclined at 30° for flexible viewing. It comes with an Abbe condenser and an iris diaphragm, enhancing image clarity. It offers coaxial coarse and fine focusing for smooth and precise adjustments. Our unit uses LED illumination to provide stable and uniform lighting during observation.

---

$1,788.00

Buy Now Catalog

Specifications

Eyepiece	WF10X/18mm
Objective	Achromatic 4X\10X\40x(S)\100X(S, OIL)
Viewing Head	Binocular Head, Inclined 30° Rotatable 360 Interpupillary Distance 48 to 75m
Nosepiece	Quadruple
Mechanical Stage	Size:140×140mm Travel Range:75×50mm Crale:0.1mm
Condenser	Abbe CondenserN.A1.25 with Iris Diaphragm
Focusing	Coaxial Coarse and Fine Adjustment, Coarse Focusing Range 30mm, Fine Focusing Interval 2µm
Illumination	LED Light

Features

• Infinite optical system
• Advanced specimen mechanism
• Adjustable phase contrast ring plate
• Live observation capability
• Long working distance objective lens

Applications

• Fluorescence Microscope NFM-300 is used for observing microorganisms with high clarity. It is applied in fields such as biology, microbiology, pathology, and medical research.
