Benchtop Colorimeter NBC-100 provides a wavelength range of 360 nm to 780 nm, ensuring accurate and precise analysis. It has a thermostatic sample tank heated up to 90°C, ensuring sample fluidity. This colorimeter utilizes CLEDs as a light source for optimal illumination. Our unit offers a range of over 30 color indicators for versatile color analysis. It includes a 7-inch touchscreen for quick and easy operation.
$4,825.00
Specifications
| Wavelength range | 360 to 780nm |
| Wavelength interval | 10nm |
| Half-band width | 5nm |
| Measuring range | 0 to 200% |
| Measurement condition | d/0(scattered light source, 0 degree viewing Angle) Comply with CIE No.15, ISO 7724/1, ASTM E1164, DIN 5033 Teil7, JIS Z8722 Condition c, ASTM D1209, ASTM D5386, ASTM D6045, ASTM D6166, ASTM D1502 |
| Integrating sphere | Φ40mm, Avian-D fully diffuse surface coating |
| Lighting source | CLEDs (Full Band Balanced Led Light Source) |
| Inductor | Dual optical sensor array sensor |
| Observer Angle | 2°/10° |
| Observation light source | A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84,ID50,ID65,LED-B1,LED-B2,LED-B3,LED-B4,LED-B5,LED-BH1,LED-RGB1,LED-V1,LED-V4 |
| Displayed Results | Pharmacopeia color number, transmission map/data, sample chromaticity value, color difference value/map, pass/fail result, color bias, color simulation, color simulation Historical data color simulation, standard sample manual input, test report |
| Measuring time | ≤ 1.5 seconds |
| Measuring optical path | Standard: 10mm glass colorimetric dish, 50mm glass colorimetric dish (optional 33mm and 100mm glass colorimetric dish) |
| Color space | CIE Lab, LCh, CIE Luv, XYZ, Yxy, transmissibility, Hunter Lab Munsell, MI, CMYK |
| Color difference formula | ΔE*ab, ΔE*CH, ΔE*uv, ΔE*cmc (2:1), ΔE*cmc (1:1), ΔE*94, ΔE*02 |
| Repeatability | Transmittance: standard deviation ≤0.08% Colorimetric value: ΔE*ab≤0.015 standard deviation, maximum ≤0.04 |
| Interstation error | ΔE*ab ＜ 0.25 |
| Heating function | No |
| Screen size | 7-inch capacitive touchscreen |
| Store data | Over 100,000 pieces of data |
| Software support | ColorExpert, Color QC2 |
| Packaging Dimensions | 570 × 420 × 340 mm |
| Net Weight | 6 kg |
| Gross Weight | 10 kg |
Features
Applications
Standard Accessories
RS-232 serial cable × 1pcAsk Expert
Labnics Benchtop Colorimeter provide a wide wavelength range for accurate and precise color measurement across various samples. These units are compatible with various cuvette options, making them suitable for different sample types. They offer multiple color indicators for versatile and comprehensive color analysis. They are capable of storing large amounts of data, ensuring convenient and efficient record-keeping. Our colorimeters ensure quick measurement speed for fast and efficient results.
